Specifications:

Working Width: 41"

Width: 57"

Height: 19 1/4"

Depth (with feed tray): 27 1/2"

Net Weight (Minus Stand): 205 lbs.

Shipping Weight: 420 lbs.

Speed: 0 -10 fpm

Maximum Temperature: 300°F

Maximum Aperture: 1/2"

Roller Diameter: 3"

Air Requirements: N/A

Electrical Requirements: 230V 30A

Stand or Cart: (included)

Footswitch: (optional)

Release Liner Rewind: (optional)

Slitter Kit: (optional)

Features:

Easy to Use

Mounter, Laminator, Encapsulator

Fast set-up and easy operation

Roller lift for easy film loading

In-line slitter for trimming during lamination (optional)

Variable roller pressure

Accepts low-melt, thermal, and pressure sensitive films

Accommodates substrates up to 1/2" thick

Accommodates rolls up to 8" in diameter

Release liner rewind (optional)

Operator-Friendly

"Ready" and "Wait" lights indicate when the laminator has reached preset temperatures

Independent upper and lower electronic temperature controls with led display

Spring-Loaded adjustable pressure on laminating and pull rollers for smooth, even lamination

Footswitch allows hands-free operation for guided materials during lamination (optional)

Auto-grip shafts for easy loading of film

Heavy Duty

Designed for mounting and laminating low-temp, thermal, and pressure sensitive films

Heated Rollers for a variety of films

Heavy-Duty forward/reverse variable speed motor

Sturdy feed-back table with adjustable feed guide

Heavy-Duty top grade silicone rubber rollers

Heavy-Duty chain and sprocket drive

Cooling Fans

Four high-capacity forced air cooling fans
